Leather Cutting Machines, Hydraulic Swing Arm Clicker Press and Hand Crank Leather Splitter for leather goods and footwear

Cowboy CB-10, CB-12, CB-16, and CB-20 Hydraulic Clicker Press

The Cowboy Model CB-16 hydraulic clicker press offers an excellent combination of value and versatility. This clicker press offers a higher tonnage alternative to other lower rated machines in the market, and yet the price of the leather clicker press is very affordable. This hydraulic swing beam clicker press can be used to both emboss leather using an embossing plate and cut leather using steel rule cutting dies.

The CB-16 generates over 16 US tons of cutting pressure. This hydraulic clicker press features a height adjustable beam to accommodate for different thicknesses of die stock as well as an aluminum plate on the underside of the cutting beam which is replaceable.

There are 4 different tonnages available in this series. 10 ton, 12 ton, 16 ton, and 20 ton.

The CB-16 leather clicker press features a heavy steel frame designed for industrial use cycles. The polypropylene cutting pad on the bed of the machine is easily replaced should it become worn.

The heavy duty hydraulic pump and cylinder of this clicker press is designed for heavy use cycles in an industrial setting. Yet this hydraulic clicker press is priced low enough that it is easily affordable for the small shop owner.

16 tons of continuous cutting pressure insures that the CB-16 will deliver enough force to use a wide variety of small, medium, and large cutting dies of variable height and thickness.

The cutting bed is sized at approximately 17X36 inches. The cutting beam is approximately 13 inches wide.

The hydraulic swing beam clicker press features an adjustable stroke timer which allows the user to control how long the machine takes to complete a compression cycle by virtue of the length of the stroke. For instance if an individual were cutting with steel rule dies the cycle time can be set for the quickest time and shortest stroke. If an individual were using the machine to emboss work using an embossing plate, the cycle timer could be set for maximum delay and longest stroke to allow for the embossing plate to leave a deep and crisp impression on the work.

The die cutting press machine has a fail safe safety mechanism built in using two joystick controllers. Both buttons must be pressed simultaneously in order for the machine to cycle. This keeps the operator's hands clear of the work.

The comparatively low price of the CB-16 when compared to other smaller tonnage machines in the market makes it an ideal choice for the small shop or manufacturer that is seeking a machine capable of producing higher tonnage than the 8-12 ton machines available in this price range. A full 16 tons of power is available with the CB-16 machine at a price that is competitive with much smaller machines.

The CB-16 swing arm hydraulic cutting press runs off of commonly available 220v single phase current. Many clicker presses of this type are made to run on 3 phase current, making them impractical for the small shop owner. The CB-16 hydraulic clicker press is set to run on 220v single phase at no additional charge. Many sellers of these machines charge close to $1000.00 for this upgrade Try a CB-16 hydraulic swing beam clicker press for your next clicker purchase and allow us to show you the Cowboy Advantage today!!!!!!

Cowboy CB-22A, CB-25A, and CB-28A Hydraulic Swing Arm Clicker Press

The Model CB-22A, CB-25A, and CB-28A leather and heavy material clicking machines offer the absolute best in product performance, reliability and versatility. These hydraulic swing arm clicker press are sold in 22, 25, and 28 ton versions respectively. These hydraulic swing beam clicker presses are available with a selector switch on the machine (optional) to vary the tonnage of each machine depending on usage or application. The selector switch varies the power available to the cutting deck in three different settings: Low, medium, and high. This allows the user to determine the correct power setting based on the the size of the cutting die or embossing plate used.

These hydraulic swing beam clicker press are available in 220 volt single phase power or 220v 3 phase power. Unlike other sellers of these machines, there is no additional up charge for a 220v single phase power setting. 220v single phase power is the preferred power setting for use in small shops and factories.

The Cowboy CB-22A, CB-25A, and CB-28A leather clicker presses also feature variable stroke timer settings which allow the user of the machine to regulate the amount of time it takes to vary the down stroke of the machine. This enables the user to regulate the time the machine takes to complete a stroke cycle. This is a very useful tool when using the machine for embossing functions, where a longer stroke time is desired.

These hydraulic clicker press, also feature many interchangeable parts with the ATOM clickers and the design has been proven over many years of service.

Consider a Cowboy swing beam die cutting press for your next clicker purchase and discover the Cowboy Advantage today!!!!

Cowboy CB-10 ECO Hydraulic Clicker Press

The Cowboy Model CB-10 ECO swing arm presses offers an excellent combination of value and versatility. This clicker press offers a higher tonnage alternative to other lower rated machines in the market, and yet the price of the leather clicker press is very affordable. This hydraulic swing beam clicker press can be used to both emboss leather using an embossing plate and cut leather using steel rule cutting dies.

The CB-10 ECO generates over 10 US tons of cutting pressure. This hydraulic clicker press features a height adjustable beam to accommodate for different thicknesses of die stock as well as an aluminum plate on the underside of the cutting beam which is replaceable.

The leather clicker press features a heavy steel frame designed for industrial use cycles. The polypropylene cutting pad on the bed of the machine is easily replaced should it become worn.

The heavy duty hydraulic pump and cylinder of this clicker press is designed for heavy use cycles in an industrial setting. Yet this hydraulic clicker press is priced low enough that it is easily affordable for the small shop owner.

10 tons of continuous cutting pressure insures that the CB-10 ECO will deliver enough force to use a wide variety of small, medium, and large cutting dies of variable height and thickness.

The cutting bed is sized at approximately 16X30 inches. The cutting beam is approximately 12 inches wide.

The die cutting press machine has a fail safe safety mechanism built in using two joystick controllers. Both buttons must be pressed simultaneously in order for the machine to cycle. This keeps the operator's hands clear of the work.

The comparatively low price of the CB-10 ECO when compared to other smaller tonnage machines in the market makes it an ideal choice for the small shop or manufacturer that is seeking a machine capable of producing higher tonnage than the 8-10 ton machines available in this price range. A full 10 tons of power is available with the CB-10 ECO machine at a price that is competitive with much smaller machines.

The CB-10 ECO swing beam die cutting press runs off of commonly available 220v single phase current. Many clicker presses of this type are made to run on 3 phase current, making them impractical for the small shop owner. The CB-10 ECO hydraulic clicker press is set to run on 220v single phase at no additional charge. Many sellers of these machines charge close to $1000.00 for this upgrade Try a CB-10 ECO hydraulic swing beam clicker press for your next clicker purchase and allow us to show you the Cowboy Advantage today!!!!!

CowBoy 8020 Leather splitting machine

The Cowboy Model CB 8020 is among one of the largest stationary blade splitters ever built for use in leather shops and by leather hobbyists.

The machine features fully adjustable split thickness levels, adjustable bottom roller tension, and a very easy to remove splitting blade.

The CB 8020 is rated to to split approximately 15-16 inch wide pieces of leather in any length. The machine excels at splitting thick leather and works down to leather that is around 6-7 ounces thick before splitting.

The micrometric thickness adjuster allows the machine to split as thin as about 1 ounce off at a time up to 12 ounces in a single pass.

Each CB 8020 is hand sharpened, adjusted, and pre lubricated prior to shipment. The blades are polished and sharpened using a centuries old "hollow grinding" technique that insures the blades will be razor sharp right out of the box.

Each 8020 machine comes complete with all items needed to run the unit, including tools, table, stand, special DC servo motor, and gear reducer drive unit.

Click here for video

8116 Hand crank leather splitter for handmade leather workshop and saddlery

The Cowboy 8116 series hand crank machine is the utimate bench mounted splitting solution for doing level splits on very heavy and thick leathers.

The gear driven bottom feeder and long crank handle affords the user the highest degree of mechanical advantage when splitting thick and tough leather hides, belts, and soles of shoes. The machine can split leather, rubber, crepe, and other natural and man made leather products with ease.

The leather craft tool features a fully adjustable thickness gauge allowing the user to efficiently control the depth of the split on each and every piece. This affords a high degree of precision when splitting mutiple pieces.

Each blade is hand sharpened and hollow ground by our expert craftsmen to insure trouble free and easy operstion. Each machine comes with a razor sharp blade out of the box!!!!

Cowboy 8116 machines are covered by our limited lifetime warranty to offer our customers piece of mind before, during, and after the sale.

Cowboy offers blase resharpening services for a very reasonable price allowing buyers to keep their machines running at peak operational efficiency.

Click here for video

Cowboy 806 Deluxe Leather Splitter for saddle making and leather crafting

This is one of the finest bench splitters manufactured today. When you see the plate steel construction of this splitter, you will know that it is ready for a lot of use. The 6" (152 mm) blade makes it great for skiving straps to a consistent thickness or just thinning down the ends for a buckle. Adjustments will let you set it to get the same results every time.

This Leather splitter is ideal for hobby or light manufacture. Used to thin (skiving) leathers down to a uniformed thickness. Fully adjustable to split most thicknesses of leather. Note these are made mainly for vegetable tanned leather.

Click here for video

CowBoy 800 Leather splitter, leather skiver

The Cowboy 800 leather splitting and skiving machine is an excellent choice for the leatherworker on a budget that requires a very sharp, efficient leather splitting machine for doing a multitude of leather splitting operations around the workshop.

Featuring the ability to do both lap skives (tapered skives) and level skives (same thickness throughout length) this machine will prove to be a workhorse in any leather workers shop.

Each blade is hand sharpened by hollow grinding by our expert craftsman to produce a blade edge that is razor sharp. Each blade is heat treated to a Rockwell hardness of Rc 65-68 which insures that the machine will hold an edge over many hours of use.

A quick and easy depth stop adjuster allows the user to level skive leather to any thickness.

Depending on the type of leather used, this machine can split leather up to 4 inches wide. A 6 inch wide blade length allows ample room for inserting wide pieces into the machine.

Each Cowboy 800 series leather craft tool is backed by our lifetime limited warranty giving the end user peace of mind in knowing that we will stand behind this machine both before, during, and after the sale.

Cowboy also offers blade resharpening services for a very affordable price to allow you to protect your investment and keep your machine running at peak efficiency.

Click here for video
